Sheaves (AS 2089) HAND OPERATED SHEAVES TO AS 2089 Bush Sheave Rope Rope Product Standard Fitted as Shaft (B) C D U/W Kg Dia. (A) Type Dia. (mm) Code pkt. size Standard Wire 5 SBH-001-30 60 12 18 21 0.4 Fibre 10 SBH-001-7 Wire 6 SBH-011-30 76 12 18 21 0.4 Fibre 12 SBH-011-7 Wire 7 SBH-021-30 89 YES 16 18 21 0.42 Fibre 14 SBH-021-7 10 Wire 8 SBH-031-30 102 20 25 28 0.8 Fibre 16 SBH-031-7 Wire 9 SBH-041-30 114 22 25 28 0.9 Fibre 18 SBH-041-7 Wire 10 SBH-051-30 127 OPTION 22 28 31 1.2 Fibre 20 SBH-051-7 Wire 12 SBH-061-30 152 5 OPTION 25 29 32 2.2 Fibre 24 SBH-061-7 Wire 14 SBH-071-30 178 YES 30 36 39 3.4 Fibre 28 SBH-071-7 Wire 16 SBH-081-30 203 OPTION 35 41 46 5.2 Fibre 32 SBH-081-7 1 Wire 18 SBH-091-30 229 45 51 55 8.2 Fibre 36 SBH-091-7 YES Wire 20 SBH-101-30 254 45 57 62 12.4 Fibre 40 SBH-101-7 POWER OPERATED SHEAVES TO AS 2089 152 8 SBP-061-20 5 25 29 32 2.2 178 10 SBP-071-20 30 36 39 3.4 203 12 SBP-081-20 35 41 46 5.2 229 13 SBP-091-20 45 51 55 8.2 254 14 SBP-101-20 45 57 62 12.4 300 WIRE 16 SBP-111-20 1 YES 50 61 65 18 350 20 SBP-124-20 55 56 60 22.5 400 24 SBP-134-20 70 65 69 29 450 26 SBP-144-20 70 65 69 32 500 28 SBP-154-20 80 70 75 41 550 32 SBP-164-20 80 74 80 48 HEAVY DUTY SHEAVES 100 10 - 11 SSB10010 25 25 28 2 150 12 - 14 SSB15012 5 30 29 32 3 150 16 – 18 SSB15018 35 37 40 3 200 18 – 20 SSB20020 35 37 40 4.6 250 WIRE 22 SSB25022 1 YES 50 48 50 9.0 300 26 SSB30026 55 56 60 15.6 350 28 SSB35028 60 56 60 19.4 400 32 SSB40032 70 65 69 30 450 32 SSB45032 70 65 69 32 Special sheaves can be manufactured to suit any application. 11 All specifications & dimensions are subject to change without notice. Ph: +(613) 9357 0277 www.superlift.com.au Fax: +(613) 9357 0621
